Technical parameters

With Midi Socket ,can make the library on the console

Power:AC100-240V /50-60Hz

DMX512channels:2048

Mating number of fixtures:200

Fixtures re-connected with the address code:support

Lamps horizontal and vertical exchange:support

Lamps channel inverting output：support

Lamps channel sliding mode switch:support

Each scanner maximum available control channels:

Channel 40 main channel +40 trim

Fixture library ：R20 pearl light library support

The number of scenes that can be saved:150

The number of scenes that can run simultaneously :15

The total number of steps in a multi-step scenario:600

Scene time control:fade in,fade out,LTP sliding

Graphics can be stored for each scene:5

Fader scenes and dimming:support

Interlock scene and dimming:support

Point control scenarios:support

Graphics generator:can generate dimmer, P/T, RGB, CMY, color, Gobo, lris,focus graphics

Graphics can be run simultaneously Number：8

Master fader:Global total control

Now black:support

Dial to adjust the channel values:support

Fader adjust the channel values:support

Fader Dimmer:support

U disk read:Support FAT32 format
